No worries, we can help you fix it and get your machine back in working order in no time! Below are some of the more common errors for the IGT S2000 platform of machines and the steps to clear them. Remember, IGT S2000 machines will 'stack' errors.
Igt Double Red White Blue Manual
Description
Double Red, White & Blue
The Double Red, White & Blue slot machine is a variation of the tried-but-true classic Red, White & Blue. The Double Red White & Blue is a all American favorite. The slot machine features the Red, White, and Blue Bars and the Jackpot symbol being the Wild Star along with the 7s in the same color fashion.
Product Description
Bill Validator accepts $1’s through $100’s
Standard casino size cabinet 48″ tall, 250 pounds
Chrome trim – Slot Machine exterior color varies
Cabinet Color: Additional pictures are available by email upon request to insure there are no misunderstandings concerning the color of the exact machine you are buying. Most machine cabinets are black but this is not the rule.
Machine Dimensions: This machine is 44 inches high and the top candle will add an additional 4 to 6 inches. The width is 22 inches and 20 inches deep. The weight is approximately 250 pounds.
Power Requirements: This machine will run on normal 110 V household current. The power cord will run out of the back of the machine. No special adaptor or wiring is needed. It is a good idea to plug the power cord into a power surge protector since there is a computer board inside this machine.
The product line
The IGT S2000 slot machine is probably the most recognizable slot machine in the world due to its wide distribution and the movie industry. Most casinos today will have these on the game floor. The IGT S2000 remains a favorite of “reel machine” enthusiast worldwide. IGT S2000 slot machines are a must have for any floor and are also one of the lowest cost slots available now.
The IGT S2000’s are the classic reel slots that you see in the casinos today. These are our most popular machines for home sales. These machines come to us coinless now from the casino- meaning they will take bills and print out a ticket; just like in a modern day casino. They can be converted back to take coins at an additional cost; however, we highly recommend keeping them coinless.
100% Fully Refurbished IGT s2000 slot machines available!
| Machine Type: | IGT |
| Machine Name: | Double Red, White & Blue |
| Type of Top: | 16in |
| Number of Coins: | 2 |
| Accepts Bills: | Yes |
| Number of Lines: | 1 |
Below are some of the more common errors for the IGT S2000 platform of machines and the steps to clear them. Remember, IGT S2000 machines will 'stack' errors. IF the machine has multiple errors, only ONE error will be cleared each time the door is opened and closed. If you know that the cause of the error has been fixed, simply lift up on the door handle/latch, and lower it back down. You do not have to physically open and close the door, just lifting and lowering the door handle will clear the error code from the screen.
If you find you need to Clear and/or Key your machine, we have easy to follow instructions. A Clear chip is not a FIX-ALL! If you have a component that has failed or is causing an error, the error will reoccur after the Clear if the problem is not remedied.
Call Attendant - Turn the brass Reset key on the side of the machine once to see the error(s).
Door Open M - Main Door is open. Close the main door.
Door Open B - Belly Door is open. Close the belly door.
Door Open MB - Door to the cash can is open. Close the door to the cash box and secure if needed.
Low Battery - Battery in the corner of the MPU board has dropped to an insufficient level. Replace with a 3.6v Lithium battery (either coin type, AA, or 1/2AA size). The battery will need to be soldered onto the board. Pease NOTE: STANDARD household batteries are NOT an acceptable replacement.
NetPlex Link Down - Usually this is caused by a failed power supply (given the machine was operating as it should prior to the error).
Now...for the fun part! Certain components in your machine can fail causing false error messages to appear. The error can be completely unrelated to the item listed in the message. For example, a Door Open messages when the door is physically closed could be a sign of bad door optics, or perhaps a failing I/O board. A Coin-In Jam error on a coinless machine can also be caused by a failed Door I/O board.
If you run into an error that you cannot get to clear, feel free to contact us or visit the great forums at NewLifeGames.com for answers!
